StimTec Neo TENS/EMS/IFC Microcurrent Unit

StimTec NEO is a lightweight, portable device with a full range of electrotherapy treatments for acute or chronic conditions, such as neck and back pain, sciatica, ankle sprain, frozen shoulder, rotator cuff tendinitis or epicondylitis.  Select from 40 pre-set programs to deliver TENS, EMS (NMES), IFC or MIC as part of a home rehabilitation program. Programs are effective and safe to use. A lock button prevents any unplanned changes to the selected program, and the device memory keeps the program setting even if the battery is removed. The low battery light indicator shows when it is time to re-charge. Unit comes with soft case, lithium battery, battery charger, lead wires and user manual.



Features

- 40 Preset Programs
- Rechargeable Lithium Battery
- Adjustable program Timers
- Electrode Placement Guide
- Backlit LED Screen
- Dual Channel
- Portable Electrotherapy
- Includes 4 Electrodes (2" x 2"), user guide, a pair of lead wires, carry case and battery charger
- 1 year warranty



22 TENS Modes

- Intensity 0-150 mA zero to peak at 500ohm load
- Frequency 1-150 Hz
- Pulse width 50 -250µs in steps of 10µs
- Waveform Symmetrical bi-phase rectangular
- Asymmetrical bi-phase rectangular Mono-phase rectangular



13 EMS Modes

- Intensity 0-150mA zero to peak at 1000ohm load each channel
- Frequency 1-110 Hz
- Pulse width Positive phase: 50-400µs, in steps of 50µs
- Waveform Symmetrical bi-phase rectangular
- Symmetrical bi-polar rectangular
- Ramp up time 0-5s in steps of 0.25s
- Ramp down time 0-5s in steps of 0.25s
- On time 1-60s in steps of 1s
- Off time 0-60s in steps of 1s



2 Microcurrent Modes

- Frequency 94Hz fixed (A)/ 0.5,8,80Hz(B)
- Pulse width 250uS fixed (A),2.1ms fixed (B)
- Waveform Mono-phase rectangular



3 IFC Manual Modes

- Carrier Frequency 4000Hz fixed (CH1)
- Modulating Frequency 4004-4160Hz, in steps of 4Hz (CH2)
- Phase width 125µs
- Waveform Symmetrical balanced Sine wave
